USB 3.1 Type C Female Plug Connector Port / Charging Port / Charger
DC Socket for electronic devices
Discraption
USB Type-C is a new, tiny, super-fast connector for the Universal
Serial Bus standard that can support a number of new standards
including USB 3.1 and USB power delivery. It has the following two
advantages:
1.It's easier to plug in
No more fiddling with the cord to make sure it's plugged in the
correct way every time, because both connection ends are the same
and there is no "upside-down." Hopefully this means fewer scratches
all over your device's charging port area from trying to plug it in
with the lights off.
2. Data transfer and power capability have greatly improved
USB 3.1 Type-C cables offer a transfer rate of 10Gbps, which is
double the transfer speed of USB 3.0 (5 Gbps). Additionally, these
cables will offer 20 volts and 5 amps of power, compared with the 5
volts and 1.8 amps of its predecessor. This means less waiting
around for devices to transfer data or for their batteries to
charge.
Applications
Like older USB technology, Type-C will also connect monitors,
external storage drives, printers, cameras and other peripherals.
One beauty of the system is that cables have the same connector on
both ends, and can be inserted into ports without worries about
which side is up or down.
We supply the Connector Port, which you can fit into your
electronics to accommodate Type C data and charging lines.
ODM and OEM is welcome.
Quick Details
| Type | Female Plug | Voltage Rating | 30V DC |
| Contact Resistance | 30 milliohms MAX | Storage temperature | -20C ~ +60C |
| Dielectnic Withstanding Voitage | 500V AC | Durability | 10000 Cycles |
| ODM / OEM | welcome | Packing | blister box |
Packaging
The charger Socket can be packed in a blister box or packaged into
a strip to accommodate an automated assembly line.
