SUJ2 Materials MISUMI Standard Shoudre Guide Pins with Oil Groove for Plastic Injection Mold

Description
Leader pins is a guide element used with components in the mold to ensure that the mold moves with precise positioning and guides the mold travel. It is usually cylindrical with shoulder and have some oil grooves.The tail is designed as a conical surface to ensure it accurately enters the guide bushings.
specification & price list of guide pillar .pdf

Material
The material of guide pins usually uses bearing steel, die steel and so on. The bearing steel 20Cr material is a high carbon chromium bearing steel ,that has been quenched and hardened to have high hardness, uniformity and wear resistance. Due to its ability to harden to HRC60 and high carbon wear resistance, it is the most widely used bearing steel. It is suitable for all kinds of bearing rings and rolling elements. It is also used to manufacture die and measuring tools, including guide pins and ejector pins of various molds...

Quick Details
Because of the reason of usage, the guide pins needs smooth surface,requiring small cylindrical tolerances and low surface roughness.

Standard Size
We have the following standard sizes of leader pins in stock, generally can be shipped within 3 working days, if customized, delivery time is generally 15-20 days. If there is an urgent need, please communicate with the seller in advance.

Packing and Shipping

The leader pins are packaged with plastic bags with rust preventing oil, customized package is welcome.
About the shipping, all the well-known express companies and ocean shipping can be selected, but in remote areas, we can only use EMS.

  Shenzhen Bede Precision Mould Co., Ltd. is a manufacturer of precision molds and accessories integrating R&D, manufacturing, sales and service.

  After 10 years of hard work, it has become an OEM processing partner for many domestic and foreign mold parts. The company has CNC lathe processing, CNC milling machine processing, precision mirror axis processing, and supporting post-processing center.

  There are many design teams formed by technical experts who have been in the mold industry for 15~20 years. The company can undertake a large number of precision molds and accessories, automatic parts processing customization.
